Features | Details | Unit |
Display Size(Diagonal) | 3.5” |
|
LCD type | MVA TFT |
|
Display Mode | Transmissive/Normally black |
|
Resolution | 480RGB x640 | Pixels |
View Direction | FULL VIEW | Best Image |
Module Outline | 64 (H) x85(V) x2.9 (T) (Note1 ) | mm |
Active Area | 53.57 (H) x 71.42 (V) | mm |
Pixel Size | 111.6 (H) x111.6 (V) | um |
Pixel Arrangement | Stripe |
|
Polarizer SurfaceTreatment | Anti-glare |
|
Display Colors | 262K |
|
Interface | 18-bitRGB interface+3 wire SPI |
|
Driver IC | HX8363-A | - |
With or Without Touch Panel | Without |
|
Operating Temperature | -20～70 | ºC |
Storage Temperature | -30～80 | ºC |
Weight | 32 | g |
